Type

Scale - 1/10th

Brushed/Brushless - BL

Sensored/Sensorless - SD

Waterproof - YES

Specifications

Cont./Peak Current - 80A/480A

Input Voltage - 2-3S Lipo/6-9 Cell NiMH

BEC Output - Switch Mode:6V/7.4V@6A

Wires & Connectors

Wires & Connectors - Black-14AWG-200mm*1 Red-14AWG-200mm*1

Output Wires - No

Input Connectors - XT60

Output Connectors - No

ESC Programing via

SET Button on ESC - Not Supported

LED Program Box - Not Supported

LCD Program Box - Not Supported

WiFi Module - Not Supported

Programming Port - Built-in bluetooth

Firmware

Firmware Upgrade - Supported

Size & Weight

Size - 47.4x36.2x26.5mm

Weight - 108g (Including the weight of input line)

Applications

Applications - Only support XERUN AXE R2 motor

Vehicles - 1/10thRock Crawler

(HW38020312)

SKU HW38020312
Barcode # 6938994416344
Brand HOBBYWING
