Features:

- Full CNC machined alloy case
- High Voltage 6.0 - 8.4V
- Titanium gears
- Ball Raced
- Coreless motor
- Ultra high speed and torque
- Water resistant

Tech. Specs:

Voltage range 6.0 - 8.4V
Speed @ 6.0V 0.09 sec/60°
Speed @ 7.4V 0.08 sec/60°
Speed @ 8.4V 0.07 sec/60°
Torque @ 6.0V 18.3 kg/cm
Torque @ 7.4V 22.6 kg/cm
Torque @ 8.4V 25.6 kg/cm
Dimensions (mm) 40.5x20.5x36
Weight 72g

General Info

Item Nr

C-52001

Barcode

8718057150549

Brand

Team Corally

Servo - Specs

Speed 60°/Sec @ 4.8V



Speed 60°/Sec @ 6.0V

0,09

Speed 60°/Sec @ 7.4V

0,08

Speed 60°/Sec @ 8.4V

0,07

Torque kg/cm @ 4.8V



Torque kg/cm @ 6.0V

18,3

Torque kg/cm @ 7.4V

22,6

Torque kg/cm @ 8.4V

25,6

Servo - Dimensions

Servo Type

Standard Servo

Spline Type

25T Spline

Length (mm)

40

Width (mm)

20

Height (mm)

36

Weight (g)

72

Servo - Technology

Technology

Digital HV

Operating Voltage (V)

6.0V - 8.4V

Servo Motor

Coreless Motor

Servo Protection

Water - Dust Resistant

Servo Positioning

VR Potentiometer - Direct Drive

Servo Gears

Titanium Gears

Servo Case

Aluminium Case

Connector

JR Universal + Colored Lead
